Model 72A - Optically Isolated Line Driver


Features
  • DC TO 19.2 KBPS
  • Optically Isolated
  • TD & RD LED's
  • Loopback Switch
  • Built-In Surge Protection
  • Male or Female Connectors
  • Screw Terminals and RJ-11



Product Description

The Model 72A
Optically Isolated Line Driver links RS-232 based devices over extended distances. It provides optical isolation and has built-in verification of operation using a loopback switch. The Model 72A communicates via 4-wire cable with another 72A, 72 or the rack mounted Model 75.

The Model 72A is designed for asynchronous operation over two twisted pair, non-loaded, metallic (DC continuity) cable up to 19.2 KBPS. Each modem is equipped with Transmit Data and Receive Data LED's to simplify installation and troubleshooting. Verification of modem operation is simplified using the built-in loopback switch. A second switch reverses pins 2 and 3 of the RS-232 connector for interfacing with either DCE or DTE devices. The Model 72A is available with male or female DB25 connectors. The 4-wire line termination includes 4 screw terminals and a modular phone jack.


Model Description Price Product Info QTY AVAIL BUY NOW!
Optically Isolated Line Driver - Male Connector - 115 Volts Specifications Manual Application Note
Optically Isolated Line Driver - Female Connector - 115 Volts Specifications Manual Application Note
Optically Isolated Line Driver - Male Connector - 220 Volts Specifications Manual Application Note
Optically Isolated Line Driver - Female Connector - 220 Volts Specifications Manual Application Note

Quantity discounts for five or more of these items may apply.
